CubiScan S9
Precision meets efficiency in every dimension
The CubiScan S9 is a state-of-the-art system for pallet and volume measurement that has been developed to optimize your shipping and storage processes as well as storage space utilization in the long term. This advanced 3D measurement system combines precise automatic volume measurement, stretch wrapping functionality and the ability to intelligently detect dangerous goods - for safe, fast and efficient logistics processes.
The CubiScan S9 revolutionizes volume measurement, automated stretch wrapping processes and dangerous goods handling through high-precision 3D laser measurement and intelligent object detection. With this intelligent measuring system, you can optimize your logistics processes sustainably - with maximum efficiency and legally relevant dimensional data in real time.
Technical specifications
Additional information
| Measuring range | 150 cm x 150 cm x 250 cm |
| Device dimensions tower | 55 cm x 55 cm x 260 cm (The dimensions depend on the wrapping machine.) |
| Measuring area | 150 cm x 150 cm x 250 cm |
| Scale division | 2 cm x 2 cm x 2 cm (confidence level 95%) |
| Minimum size of packages | 20 cm x 20 cm x 20 cm |
| Measuring time | approx. 5 additional revolutions required (depending on the packaging machine) |
| Weighing scale | depending on the wrapping machine |
Technical details
Further information can be found in the data sheet.
See product in action
For a complete overview of the capabilities of the CubiScan S9, please watch this and the following demo video.
Main features
- Simple installation
Set up, connect and measure immediately - the CubiScan S9 can be quickly integrated into existing processes and enables a smooth start to automatic volume measurement.
- Precise measurement & high efficiency
Using the latest LiDAR and 3D measurement technology, the CubiScan S9 measures pallets up to 2.4 meters in length - even while they are rotating at up to 16 rpm. The measured dimensional data is provided reliably and in real time.
- Integrated image recording
Built-in cameras generate high-resolution images of each side of the pallet. This image processing supports documentation, facilitates damage assessment and reduces subsequent charges by carriers.
- Dangerous goods detection
Thanks to intelligent object recognition, the CubiScan S9 automatically identifies UN dangerous goods symbols, for example, and thus ensures compliance with legal regulations. This increases safety in logistics and minimizes risk.
- Seamless stretch wrapping function
The combination of volume measurement and stretch wrapping in a single operation significantly reduces processing time and labor costs - for highly efficient logistics automation and optimal process integration.
- Legal relevance
The system is type-tested and meets the requirements for legally relevant use in accordance with the EU Measurement Directive (LFT). The precise freight measurement can therefore be used for exact invoicing.
