APACHE portal first choice
Compact. Mobile. Economical.
The APACHE portal first choice offers the proven precision of APACHE technology in a compact, transportable system. The solution is ideal for companies looking for a flexible and price-conscious entry into automated freight measurement.
Equipped with two laser scanning heads, weight recording, photo documentation and legally relevant data transmission, you get everything you need for precise and efficient logistics - reduced to the essentials.
Precise measurement, simple integration and genuine mobility: this compact entry into the world of 3D measurement and weight recording combines cost-effectiveness with reliable data quality.
Simply measure. Start quickly. Decide efficiently - with AKL-tec.
Technical specifications
Additional information
| Max. measuring area | 180 cm x 200 cm x 250 cm |
| Device dimensions | 240 cm x 230 cm x 320 cm |
| Measuring surface | 180 cm x 200 cm x 250 cm |
| Scale division | 2 cm / 2 cm / 1 cm |
| Minimum package size | 20 cm x 20 cm x 10 cm |
| Movement speed | approx. 0.4 m/sec. |
| Scale | 150 cm x 125 cm, max. 2,000 kg |
Technical details
Further information can be found in the data sheet.
Main features
- Compact, robust and mobile
Thanks to its small dimensions and robust design, the system is easy to transport, quick to install and flexible to use in different locations - measuring flexibility at the touch of a button.
- Automatic volume and weight measurement
Two laser scanning heads on the measuring beam reliably record length, width, height and volume; an integrated scale provides the weight - for legally compliant master data recording in a single operation.
- Integrated photo documentation
The optional camera creates a photorealistic image of the freight item for digital archiving, verification or further analysis - directly linked to the measuring process.
- Plug-and-play operating concept
Set up - connect - start: operation is intuitive via a barcode scan or manual start. The system provides dimensional data and weight in seconds.
- Relevance & amortization through data quality
All recorded data is legally usable in accordance with the EU Measurement Directive. At the same time, the system helps to identify incorrectly declared consignments and thus to ensure rapid refinancing.
